ROYAL EXCLUSIV Red Dragon® 3 Mini Speedy 60 Watt / 5.5m³

Regular price $1,999.00

In Stock

  • FREE Delivery over $60

Red Dragon ® 3 Mini Speedy Pump 60 Watt / 5.5m³

Technical data Red Dragon ® 3 Mini Speedy Pump 60 Watt 5.5m³:
60 Watt/h 4.25 mtr. Height of rise
with 10V control input (prepared)
speed-adjustable brushless DC (direct current) pump
Watt/percentage display
Suction side 40 mm - pressure side 25 mm
Operating voltage: 230 volts 50 Hz  (also available in 110V/60Hz)
Protection class pump: IP 68 Control unit: IP 66
Weight of pump and control unit: 3.2 kg
Hirschmann plug-in connection for detaching the pump from the controller.
Height of the suction side: middle 70 mm
Dimensions of the pump: 110 mm wide / 200 mm long / ~ 160 mm high
Dimensions control unit: 120 mm wide / 170 mm long / ~ 65 mm high

pdf_icon  Data_sheet_and_spare_parts.pdf    pdf_icon  Operating_and_maintenance_manual.pdf

  • seawater resistant M6 Grade2 titanium screws
  • seawater-proof parabolic rubber feet for acoustic decoupling
  • Extremely low-noise brushless DC feed pump with encapsulated power electronics
  • High-efficiency technology "Made in Germany"
  • Suction and pressure side, complete DIN screw connection, compact design
  • High performance ceramic plain bearings
  • the only seawater-resistant feed pump with titanium rotor, titanium stator and shrunk plain bearings
  • Easiest handling and maintenance, low risk of calcification thanks to polished titanium parts
  • heavy and solid design, against vibrations and interference oscillations
  • CE compliant and developed and built according to VDE guidelines
